The FLIR A700f Advanced Smart Sensor is a rugged, outdoor thermal camera with built-in analytics and alarming for high-resolution condition monitoring and early fire detection.
FLIR A700f Advanced Smart Sensor Thermal Cameras are ideal for users who want built-in, on-camera analytics and alarm capabilities for outdoor condition monitoring and early fire detection applications. These cameras can help companies protect assets, improve safety, maximize uptime, and minimize maintenance costs. Featuring a protective housing designed to withstand harsh environmental conditions, FLIR A700f cameras combine unmatched thermal imaging with edge computing and industrial internet of things (IIoT) for simplified inclusion in new or existing networks. For VMS integrations, thermal and visible streams can be viewed independently or simultaneously. The cameras are easy to add, set up, and operate in HMI/SCADA systems, offering automation system solution providers a running start.
| Feature | Details |
|---|---|
| Integration & Connectivity | Multiple communication and control options for easy integration into standard security and IIoT systems, including HMI/SCADA, ONVIF, Modbus TCP, MQTT, EtherNet/IP, and REST API |
| Thermal Resolution | Up to 640 × 480 for high-detail temperature monitoring across large outdoor areas |
| Image Enhancement | FSX® (Flexible Scene Enhancement) technology improves image clarity and measurement reliability |
| Focus & Optics | Remote motorized focus with multiple fields of view; f-number options: 14° (f/1.5), 24° (f/1.3), 42° (f/1.1), 80° (f/1.3) |
| Accuracy | ±2°C (±3.6°F) or ±2% of reading for ambient temperatures between 15°C and 35°C (59°F to 95°F) |
| Temperature Range | –30°C to 50°C (–22°F to 122°F) |
| Measurement & Analysis | Advanced on-camera analysis, including spotmeters, boxes or mask polygons, deltas, isotherms, iso-coverage, reference temperature, lines, and polylines (up to 12 measurement functions simultaneously) |
| Automatic Detection | Automatic hot and cold detection with max/min temperature values and position displayed within defined areas |
| Alarm Functions | Alarms triggered by selected measurement functions, digital inputs, or internal camera temperature |
| Alarm Outputs | Digital output, email (SMTP), EtherNet/IP, Modbus TCP server, MQTT, FTP file transfer, REST API queries, and image or video storage |
| Digital I/O | Terminal block inside housing; 2× opto-isolated digital inputs and 3× opto-isolated digital outputs, including a dedicated fault output (NC) |
| Video & Radiometric Streaming | Video streaming via H.264, MPEG-4, or MJPEG; radiometric streaming using FLIR radiometric format with compressed JPEG-LS |
| Image Frequency | 30 Hz for monitoring dynamic outdoor environments |
| Environmental Compliance | Meets EN50130-4, EN61000-6-3, EN55022 Class B, and FCC Part 15 Class B EMC standards |
| Mounting Options | Pole and wall mounting adapters available (sold separately) |
| Design | Rugged outdoor housing designed for harsh environmental conditions |
Need assistance selecting the right lens option, mounting kit, or integration bundle? I’d be happy to help tailor it to your project requirements!
