The FLIR A6301 cooled MWIR thermal camera provides precise, high-speed temperature measurement for demanding process monitoring and quality assurance environments.
The FLIR A6451 is a high-performance cooled MWIR automation camera designed for advanced process control, quality assurance, and non-destructive testing applications. As part of the A6400-Series, it delivers exceptional thermal sensitivity and fast frame rates, enabling accurate temperature measurement on fast-moving products and dynamic industrial processes.
Built on proven A6700-Series electronics, the A6451 supports industry-standard GigE Vision and GenICam protocols for seamless system integration. An industry-leading long-life linear cooler minimizes maintenance requirements, making the camera well-suited for continuous 24/7 automation in demanding manufacturing and test environments.
Cooled MWIR Performance for High Sensitivity
HOT MWIR detector delivers exceptional thermal sensitivity, enabling detection of subtle temperature differences in critical processes.
Fast Frame Rates for Dynamic Applications
Programmable frame rates up to 125 Hz support accurate temperature measurement on moving products and rapid thermal events.
Long-Life Linear Cooler
Industry-leading 27,000-hour cooler life supports continuous operation with reduced maintenance and predictable uptime.
Seamless Automation Integration
Supports GigE Vision and GenICam for easy integration into machine vision, automation, and process control systems.
Non-Destructive Testing (NDT)
Battery testing, composite inspection, and aircraft material analysis requiring high sensitivity and fast response.
Process Control & Monitoring
Real-time temperature monitoring in industrial manufacturing environments.
Quality Assurance
Thermal validation during production to ensure consistency and detect defects early.
Seal Integrity Inspection
Heat seal inspection in food, beverage, and pharmaceutical manufacturing.
Machine Vision Operations
Integration into automated inspection systems for temperature-based decision making.
| Feature | Details |
|---|---|
| Detector Type | FLIR HOT MWIR (SLS), cooled |
| Spectral Range | 3.0 – 5.0 µm |
| Resolution | 640 × 512 |
| Detector Pitch | 15 µm |
| Thermal Sensitivity (NETD) | <30 mK (25 mK typical at 30°C) |
| Frame Rate | Programmable from 0.0015 Hz up to 125 Hz |
| Integration Time | 480 ns to full frame |
| Dynamic Range | 14-bit |
| Radiometric Streaming | Gigabit Ethernet (GigE Vision) |
| Command & Control | GenICam (GigE), RS-232 |
| Standard Temperature Range | –20°C to 350°C (–4°F to 662°F) |
| Optional Temperature Ranges | Up to 3000°C (5432°F) with ND filters |
| Accuracy | ±2°C or ±2% of reading (±1°C typical) |
| Cooling | FLIR FL-100 linear cooler (27,000-hour life) |
| Operating Temperature | –20°C to 50°C (–4°F to 122°F) |
| Power | 24 V DC (<24 W steady state) |
